DP03 7KW-22KW
The DP03 EV Wallbox Charger is specially designed for Tesla and universal electric vehicles, supporting 7kW to 22kW adjustable power and multiple voltage inputs (220V/380V, 240V/400V, 250V). Equipped with a 4.3-inch LCD screen and LED indicators, it provides clear charging status display. With IP65 protection level, complete electrical safety protections and durable PC housing, it features natural cooling and long service life, making it suitable for home, commercial and public charging scenarios. Customizable communication modes meet diverse needs.
WALLBOX EV CHARGER
DP03 7KW-22KW
6 Core Advantages
| ✅ High Power 7KW-22KW Adjustable | ✅ 220V/380V Wide Voltage Compatible |
| ✅ 4.3-inch LCD Screen + LED Indicator | ✅ IP65 Waterproof & Dustproof |
| ✅ Long Life >10,000 Plug Cycles | ✅ Wifi & Bluetooth (Optional) |
Product Description
The DP03 EV Wallbox Charger is specially designed for Tesla and universal electric vehicles, supporting 7kW to 22kW adjustable power and multiple voltage inputs (220V/380V, 240V/400V, 250V). Equipped with a 4.3-inch LCD screen and LED indicators, it provides clear charging status display. With IP65 protection level, complete electrical safety protections and durable PC housing, it features natural cooling and long service life, making it suitable for home, commercial and public charging scenarios. Customizable communication modes meet diverse needs.
Product Parameters
| Product Model | DP03 7KW-22KW |
| Product Size | 350mm*220mm*80mm |
| Package Size | 520mm*300mm*150mm |
| Net Weight | ＜5kg |
| Housing Material | PC |
| Mating Cycle Life | ＞10,000 times |
| Input/Output Voltage | 220V/380V, 240V/400V, 250V |
| Max Output Current | 16A/32A/30A/40A/48A |
| Rated Power | 7kW~22kW, 7kW~11.5kW, 7kW |
| Frequency | 50Hz/60Hz |
| RCD | Type A or B + DC6mA |
| User Interface | LED Indicator, 4.3 inch LCD Screen |
| Communication Method | Wifi, Bluetooth(Optional) |
| Working Temperature | -30℃ ~ +55℃ |
| Working Humidity | 5% ~ 95% |
| Working Altitude | ＜2000m |
| Cooling Method | Natural Cooling |
| Ingress Protection | IP65 |
| Electrical Protection | Over/Under Voltage, Over Current, Lightning, Leakage, Short Circuit, Temperature Monitoring |
| Flame Retardant Rating | UL94V0, Fire-resistant Materials |
| Cable Material | TPU, Copper |
| Cable Length | 5m (Customize) |
