7kW Small DC Electric Vehicle Charger
This compact DC charging station adopts high-power power modules built with Silicon Carbide (SiC) MOS technology, featuring sufficient design margin for enhanced safety and reliability.
It utilizes a new high-efficiency three-phase PFC circuit topology, with a power factor above 0.95 and total harmonic distortion ≤ 5%. The high-frequency switching power module integrates advanced phase-shifted soft-switching technology to deliver superior operating efficiency.
Digital current sharing technology effectively improves current sharing accuracy and anti-interference performance. The innovative module sleep and rotation technology ensures the system runs at high efficiency continuously.
It provides intelligent charging process control with comprehensive monitoring and protection for straightforward operation, supports optional GPRS networking, and adopts hot-swappable module design for simplified maintenance.
7kW Small DC Electric Vehicle Charger
Product Overview
This compact DC charging station adopts high-power power modules built with Silicon Carbide (SiC) MOS technology, featuring sufficient design margin for enhanced safety and reliability.
It utilizes a new high-efficiency three-phase PFC circuit topology, with a power factor above 0.95 and total harmonic distortion ≤ 5%. The high-frequency switching power module integrates advanced phase-shifted soft-switching technology to deliver superior operating efficiency.
Digital current sharing technology effectively improves current sharing accuracy and anti-interference performance. The innovative module sleep and rotation technology ensures the system runs at high efficiency continuously.
It provides intelligent charging process control with comprehensive monitoring and protection for straightforward operation, supports optional GPRS networking, and adopts hot-swappable module design for simplified maintenance.
Key Features
- Intelligent Design
Digital current sharing technology improves both current sharing accuracy and anti-interference performance. Module sleep and rotation technology optimizes system efficiency and reduces ineffective energy loss. Multi-mode charging with real-time monitoring enables smart interaction, suitable for remote operation and diverse user demands. - Comprehensive Safety Protection
Air-isolated and lightning protection design blocks grid surges and provides dual-layer protection for the device. Full-process monitoring responds instantly to charging abnormalities. The hot-swappable module structure guarantees operator safety during maintenance. - Energy Saving & Low Noise
Three-phase PFC topology achieves PF > 0.99 and THDi ≤ 5%, with excellent grid compatibility. Full-bridge phase-shifted soft switching cuts high-frequency switching loss and standby power consumption. Intelligent noise reduction with dual electromagnetic and structural damping ensures quiet operation. - High Efficiency & Easy Deployment
Silicon Carbide (SiC) MOS modules feature high power density and redundancy design for reliable performance. Ultra-wide voltage output covers 99% of EV models for multi-scenario applications. The all-in-one structure supports fast deployment even in space-limited sites, minimizing operation costs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AF-DC-07-B/L-A-Z-2/4-H |
| Rated Power | 7kW |
| Input Voltage | AC 220V ± 20% |
| Product Dimensions | 540 × 320 × 92 mm |
| Efficiency | ≥ 94% (at 750V, above 50% load) |
| Charging Modes | Auto full charge / Preset energy amount / Preset charging cost / Scheduled charging time |
| Activation Methods | RFID card charging / QR code scanning charging / Switch activation |
| Network Connectivity | 4G |
| Noise Level | ≤ 65dB |
| Ingress Protection Rating | IP54 |
| Protection Functions | Over-voltage protection, under-voltage protection, overload protection, short-circuit protection, grounding protection, over-temperature protection, low-temperature protection, insulation monitoring, reverse polarity protection, lightning protection, emergency stop protection, leakage protection |
Certifications & Connector Options
- China Compulsory Certification (3C Certified)
- Available connector standards: US Standard, European Standard, Chinese GB Standard, Japanese Standard
