7kW AC Electric Vehicle Charger
This AC charging station delivers AC power at 50/60Hz with a rated voltage of 220V±20%. Designed for electric vehicle charging, this on-board charging solution suits the following scenarios:
- Large, medium and small electric vehicle charging stations
- Public areas with dedicated EV parking spaces, including urban residential communities, shopping plazas and power business premises
- Transportation hubs such as expressway service areas, bus stations and wharves
- Real estate development and construction project acceptance requirements
7kW AC Electric Vehicle Charger
Product Overview
This AC charging station delivers AC power at 50/60Hz with a rated voltage of 220V±20%. Designed for electric vehicle charging, this on-board charging solution suits the following scenarios:
- Large, medium and small electric vehicle charging stations
- Public areas with dedicated EV parking spaces, including urban residential communities, shopping plazas and power business premises
- Transportation hubs such as expressway service areas, bus stations and wharves
- Real estate development and construction project acceptance requirements
Key Features
- 7kW High-Efficiency Charging
Powered by 220V single-phase grid and compatible with most mainstream new energy vehicles. It achieves a theoretical charging speed of up to 7km per hour, allowing a full charge in 4-6 hours during off-peak nighttime hours. - Wide Voltage Adaptability
Operates stably across a 160V-260V voltage fluctuation range, ensuring reliable and consistent charging performance even in unstable grid environments such as rural areas and aging residential communities. - Intelligent Temperature Control System
Built-in temperature sensors monitor charging status in real time and automatically adjust power output, ensuring safe, stable and long-term operation of the equipment. - Comprehensive Electrical Protection Matrix
Equipped with 30mA active leakage protection, over-current / over-voltage / under-voltage protection, lightning protection (8/20μs impulse current 20kA), and real-time charging connector temperature monitoring.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AF-AC-07-B-A-Z-1/2/3/4-SF |
| Rated Power | 7kW |
| Input Voltage | AC 220V ± 20% |
| Product Dimensions | 304 × 191 × 95 mm |
| Output Current | 32A |
| Charging Modes | Auto full charge / Preset energy amount / Preset charging cost / Scheduled charging time |
| Activation Method | Plug-and-charge / RFID card activation |
| Network Connectivity | WiFi + 4G |
| Noise Level | ≤ 40dB |
| Ingress Protection Rating | IP54 |
| Protection Functions | Over-voltage protection, under-voltage protection, overload protection, grounding protection, over-current protection, emergency stop protection, leakage protection, over-temperature protection |
Certifications & Custom Options
- China Compulsory Certification (3C Certified)
- Available connector standards: US Standard, European Standard, Chinese GB Standard, Japanese Standard
- 3 optional colors for appearance customization
